The Unit accepts an input sync signal at the rear panel BNC labeled “SYNC IN.” Internal Clock Accuracy: +/-25 ppm (Parts Per Million) Lavry Engineering Blue 4496-5 4-Channel AD Converter Assembly Specifications Lavry Engineering Blue 4496-5 4-Channel AD Converter Assembly Applications
#Analog to digital converter dynamic range plus
Option to output digital audio 24 bit, 16 bit, or 16 bit plus dither and acoustic ßit Correction™ noise shaping.Īnalog and Digital Saturation modes allow hotter recording levels. One M-SYNC provides clocking and synchronization for all MAD824 AD converter modules contained in the same 4496 chassisĢ channels of sonically transparent 24 bit Lavry A-to-D conversion Wide lock mode is available for non-standard sample rates or vari-speed operation Ultra-stable crystal-referenced internal or external sync operation at 44.1, 48, 88.2, and 96 kHz Lavry Engineering Blue 4496-5 4-Channel AD Converter Assembly Features All MAD-824 units in a 4496 frame receive the same clock signal from the M-SYNC to minimize jitter and inter-channel timing differences. It receives its clock (internal or external) from the M-SYNC board (multi channel sync). The MAD-824 is a two-channel unit, converting analog audio to AES digital output in word lengths of 16, 20, or 24 bits. The Lavry Engineering Blue M.SYNC 4496 Clock Module provides clock and external synchronization to all AD modules in a chassis of LavryBlue 4496 System, as well as a BNC Word Clock output. One popular configuration is 2-channels AD, 2-channels of DA and 2-channels of MicPre.Another advantage is that the LavryBlue can initially be purchased in a “minimal” configuration and then later upgraded to add more channels or different functions, as the user’s needs change. The unit may be configured for any mix of functions-for example: 2 channels of AD and 2 channels of DA, or 6 channels of AD plus 2 channels of DA. This flexible design means that the Lavry Blue chassis can be configured to accommodate anything from a single module for stereo AD or DAconversion, to a maximum of eight channelsof conversion. Each module has a front panel and a rear panel that are directly in-line with each other from front-to-back in the 4496 chassis. The MicPre is also 2-channel, but it takes up the space of two AD or DA modules, so one chassis can provide up to four channels of microphone preamplification. Most modules are single width 2-channel units, so the chassis has space for up to eight channels of conversion or processing. The chassis provides room for up to 4 “single width” modules. SYNC-to minimize jitter and operate multiple channels in phase.One of the advantages of this approach is the ability for AD converters to “share” acommon clock source-the M This interconnection also provides for communication between the units that in some cases are user selectable. The modules are bolted in and connected to each other in a daisy chain manner, enabling power distribution across the chassis. The Lavry Blue chassis contains a power supply equipped with additional output power noise filtering. The hardware is designed to operate at industry standard 44.1, 48, 88.2 and 96 kHz sampling rates, with the additional flexibility in “Wide Mode” of operation from external clocks at non-standard or variable sample rates in the ranges of 42 to 50 kHz and 84 to 100 kHz. The LavryBlue System is a modular 1U high 19 inch rack unit, configurable to accommodate multiple functions including Digital to Analog conversion, Analog to Digital conversion, and Microphone Pre-amplification. The MSYNC module provides clock and external synchronization to all AD modules in a chassis, as well as a BNC Word Clock output. The 4496 can be ordered with as few as one module or up to eight channels of conversion. Each converter module occupies one slot and each MicPre module occupies two slots. There are four "slots" available in each 4496 chassis, and multiple chassis can be used together for additional channels in multi-track applications. The LavryBlue 4496 is a modular system that can house stereo AD, DA, and MicPre modules. MicPre's are 'double width' for 2 channels plus conversion or 4 channels MicPre in each chassis.
#Analog to digital converter dynamic range professional
Other optional configurations include dual channel professional microphone preamps. Most modules can be added by the user to an existing 4496 (with space) for added functionality as needs change.
With configurations of less than four modules, the Lavry Engineering Blue 4496 offers room for growth. The Lavry Engineering Blue 4496-5 4-Channel AD Converter Assembly is a system that contains two A/D Conversion Modules and one M-SYNC Master Clock sync board in 1U, 19 inch rack mountable chassis. Lavry Engineering Blue 4496-5 4-Channel AD Converter Assembly
